System Type | Active Loudspeaker |
Active or Passive | Active |
Program Power (Watts) | 1400 watts (4400 watts peak) |
Max SPL (dB) | 133dB Peak (128dB Continuous) |
Frequency Response (Hz +/- 3dB) | 45Hz to 26kHz |
Crossover Frequency (Hz) | 1.25kHz |
Driver Configuration | 12-inch / 1-inch |
HF Driver(s) | 38mm Voicecoil w/ 1-inch Exit |
HF Dispersion (°H x °V) | 85 x 50 |
HF Protection | Thermal/Peak Limiter |
LF Driver(s) | 12-inch (3 inch voicecoil) |
LF Protection | Thermal/Multiband Peak Limiter |
LF Processing | Dynamic Bass Extension |
Cooling Scheme | Passive |
Power Cable | Detachable IEC |
Power Consumption (typ/max) | 2.4A/3.0A @ 120Vac 1.2/2.5 A @230Vac |
Inputs | 1/4-inch, XLR, RCA |
Inputs – 1/4″ Jacks | Yes (x2) |
Inputs – XLR | Yes (x2) |
Input Sensitivity (Vrms Sine) | 1.23 Vrms +4dBu |
Mixer Controls | Sub Mode HPF, Bass Boost, Mixer Enable |
Level Controls | Master Level, Mic Level, Line Level |
LED Indicators | Power, Limit, Clip |
Bar Handles | Yes |
Flying Hardware | EYEBOLT1/4A |
Pole Mount Adapter (1 3/8″-3.5cm) | Yes |
Enclosure Materials | ABS |
Baffle Material | ABS |
Grille | Perforated Metal |
Dimensions (DWH xbackW, inches) | 13.5 x 16.7 x 26.5 |
Dimensions (DWH xbackW, cm) | 34.3 x 42.5 x 66.7 |
Weight (lbs/kg) | 60 / 26.3 |
